Focusing system
Internal focusing system
Minimum focus distance
0.28 m (0.92 ft) from focal plane at all zoom positions
Aperture range
f/2.8 to 22
Maximum aperture
f/2.8
Minimum aperture
f/22
Internal focusing
Yes
Focal length
14–24 mm
Maximum reproduction ratio
0.13x (24 mm focal length)
No. of diaphragm blades
9 (rounded diaphragm opening)
Weight
Approx. 650 g (1 lb 7 oz)
Focal length scale
Graduated in millimeters (14, 15, 16, 18, 20, 24)
Supplied accessories
LC-Z1424 Lens Cap (front cap), LC-K104 Lens Cap (front cap), LF-N1 Lens Cap (rear cap), HB-96 Lens Hood, HB-97 Lens Hood, CL-C2 Lens Case
Type
Nikon Z mount
Format
FX/35 mm
Focusing
Auto, Manual
Diameter x length (extension from lens mount)
Approx. 88.5 mm/3.5 in. maximum diameter x 124.5 mm/5 in. (distance to end of lens from camera lens mount flange)
Angle of view
FX format: 114° to 84°, DX format: 90° to 61°
Coating
Nano Crystal Coat, Fluorine coat, ARNEO coat
Autofocus
Yes
Lens construction
16 elements in 11 groups (including 4 ED elements, 3 aspherical elements, elements with Nano Crystal and ARNEO coats, and a fluorine-coated front lens element)
