Tripod socket
1/4–in. (ISO 1222)
Picture Control System
Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat, Creative Picture Controls (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls
Viewfinder
1.27-cm/0.5-in. approx. 3690k-dot (Quad VGA) OLED electronic viewfinder with color balance and auto and 11-level manual brightness controls
Multiple exposure
Add, average, lighten, darken
Operating environment - temperature
0 °C to 40 °C (+32 °F to 104 °F)
Storage file formats
NEF (RAW): 12 or 14 bit (lossless compressed or compressed), JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available, NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
Lens VR
Lens shift (available with VR lenses)
Flash sync speed
X=1/200 s; synchronizes with shutter at 1/200 s or slower; auto FP high-speed sync supported
Lens servo
Single-servo AF (AF-S), Continuous-servo AF (AF-C), full-time AF (AF-F; available only in movie mode); predictive focus tracking, Manual focus (M): Electronic rangefinder can be used
Focus points
273 (Number of focus points available in photo mode with single-point AF selected for AF-area mode and FX selected for image area)
Flash modes
Front-curtain sync, slow sync, rear-curtain sync, red-eye reduction, red-eye reduction with slow sync, off
Frame advance rate
Continuous L: Approx. 1 to 4 fps; Continuous H: Approx. 4.5 fps (Maximum frame advance rate as measured by in-house tests.)
Release mode
S (single frame), CL (continuous low speed), CH (continuous high speed), Self-timer
Battery
One EN-EL15c rechargeable Li-ion battery?
Flash control
TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering
Movie - audio recording format
Linear PCM (for movies recorded in MOV format), AAC (for movies recorded in MP4 format)
Accessory shoe
ISO 518 hot-shoe with sync and data contacts and safety lock
Movie - metering method
Matrix, center-weighted, or highlight-weighted
Operating environment - humidity
85% or less (no condensation)
Compatible lenses
Z mount NIKKOR lenses F mount NIKKOR lenses (mount adapter required; restrictions may apply)
Other options
HDR (high dynamic range), photo mode flicker reduction
Movie - video compression
H.264/MPEG-4 Advanced Video Coding
Exposure compensation
–3 to +3 EV (choose from step sizes of 1/3 and 1/2 EV) available in modes P, S, A, and M
Storage media
2 Secure Digital (SD) cards, the card in Slot 2 can be used for overflow or backup storage or for separate storage of NEF (RAW) and JPEG images; pictures can be copied between cards.
Total pixels
24.93 million
Movie - audio recording device
Built-in stereo or external microphone with attenuator option; sensitivity adjustable
Eyepoint
21 mm (-1.0 m-¹; from center surface of viewfinder eyepiece lens)
ISO sensitivity
ISO 100 to 51200, in steps of 1/3 or 1/2EV, can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 102400 equivalent) above ISO 51200; auto ISO sensitivity control available
Wi-Fi (Wireless LAN) operating frequency
2412 to 2462 MHz (channel 11)
Image size (pixels)
[FX (36 x 24)] selected for image area: (L)6016 x 4016 (24.2 million), (M)4512 x 3008 (13.6 million), (S)3008 x 2008 (6.0 million); [DX (24 x 16)] selected for image area: (L)3936 x 2624 (10.3 million), (M)2944 x 1968 (5.8 million), (S)1968 x 1312 (2.6 million); [1:1 (24 x 24)] selected for image area: (L)4016 x 4016 (16.1 million), (M)3008 x 3008 (9.0 million), (S)2000 x 2000 (4.0 million); [16:9 (36 x 20)] selected for image area: (L)6016 x 3384 (20.4 million), (M)4512 x 2536 (11.4 million), (S)3008 x 1688 (5.1 million); Photographs taken while filming movies at a frame size of 3840 x 2160: 3840 x 2160; Photographs taken while filming movies at other frame sizes: 1920 x 1080
Movie - Other options
Time-lapse movie recording, electronic vibration reduction, time codes
Wi-Fi (Wireless LAN) maximum output power
0.7 dBm
Weight
Approx. 675 g (1 lb. 7.9 oz.) with battery and memory card but without body cap; approx. 590 g/1 lb. 4.9 oz. (camera body only)
Dimensions (W x H x D)
Approx. 134 x 100.5 x 69.5 mm (5.3 x 4.0 x 2.8 in.)
Effective angle of view
FX
Flash-ready indicator
Lights when optional flash unit is fully charged; flashes as underexposure warning after flash is fired at full output
Exposure metering
TTL metering using camera image sensor
Image sensor
CMOS, 35.9 mm x 23.9 mm
AF-area mode
Pinpoint (available in photo mode only), single-point, and dynamic-area AF (available in photo mode only); wide-area AF (S); wide-area AF (L); auto-area AF
Movie - Active D-Lighting
Same as photo settings, Extra high, High, Normal, Low, and Off
Autofocus
Hybrid phase-detection/contrast AF with AF assist
Bracketing types
Exposure and/or flash, white balance, ADL
Shutter speed
1/8000 to 30 s (choose from step sizes of 1/3 and 1/2 EV), bulb, time, X200
Audio input
Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)
Accessory terminal(s)
Built-in (can be used with MC-DC2 remote cords and other optional accessories)
Self-timer
2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s
Active D-Lighting
Auto, Extra high, High, Normal, Low, and Off
Bluetooth standards
Bluetooth Specification Version 4.2, Bluetooth: 2402 to 2480 MHz Bluetooth Low Energy: 2402 to 2480 MHz, Bluetooth: –4.8 dBm Bluetooth Low Energy: –6.3 dBm; Approximately 10 m (32 ft)?
Supplied accessories
BF-N1 Body Cap, DK-29 Rubber Eyecup (comes attached to camera), EN-EL15c Rechargeable Li-ion, Battery with terminal cover, MH-25a Battery Charger (comes with either an AC wall adapter or power cable of a type and shape that varies with the country or region of sale), AN-DC19 Strap, UC-E24 USB Cable, BS-1 Accessory Shoe Cover
Focus lock
Focus can be locked by pressing shutter-release button halfway (single-servo AF/AF-S) or by pressing the center of the sub-selector
Monitor
8-cm (3.2–in.) diagonal; Tilting TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage, and color balance and 11-level manual brightness controls; Approx.1040k-dot
Flash compensation
-3 to +1 EV in steps of 1/3 or 1/2 EV, available in modes P, S, A, and M
Wi-Fi (Wireless LAN) standards
IEEE 802.11b/g/n
Movie - metering
TTL exposure metering using main image sensor, TTL metering using camera image sensor
Movie - file format
MOV, MP4
Magnification
Approx. 0.8x (50 mm lens at infinity, -1.0 m-¹)
Lens mount
Nikon Z mount
Shutter type
Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter
Movie - frame size (pixels) and frame rate
3840 x 2160 (4K UHD): 30p (progressive)/25p/24p; 1920 x 1080: 60p/50p/30p/25p/24p
Battery pack
MB-N10 battery pack (available separately); takes two EN-EL15c? batteries
Detection range
-3 to +19 EV,³ Without low-light AF: -2 – +19 EV
USB
Type C connector (SuperSpeed USB); connection to built-in USB port is recommended
Frame coverage
Approx. 100% horizontal and 100% vertical
Mode
Auto, P: programmed auto with flexible program, S: shutter-priority auto, A: aperture-priority auto, M: manual U1, U2 and U3: user settings modes
Nikon Creative Lighting System
i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, auto FP high-speed sync, unified flash control
Playback
Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, playback zoom cropping, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, location data display, auto image rotation, and picture rating
Wi-Fi (Wireless LAN) security
Open system, WPA2-PSK
Eye sensor
Automatically switches between monitor and viewfinder displays
Effective pixels
24.3 million
Metering range
-3 to +17 EV (ISO 100, f/2.0 lens, 20 °C/68 °F)
Dust-reduction system
Image sensor cleaning, Image Dust Off reference data (Capture NX-D software required)
AC adapter
EH-7P charging AC adapter (available separately); EH-5d/EH-5c/EH-5b AC adapter, requires EP-5B power connector (available separately)
Metering method
Matrix metering Center-weighted metering: weight of 75% given to 12 mm circle in center of frame; weighting can instead be based on average of entire frame Spot metering: meters 4 mm circle (about 1.5% of frame) centered on selected focus point Highlight-weighted metering
White balance
Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (7 types), flash, choose color temperature (2500 K to 10,000 K), preset manual (up to 6 values can be stored), all with fine-tuning except choose color temperature
HDMI output
Type C HDMI connector
Type
Mirrorless
File system
DCF 2.0, Exif 2.31
Diopter adjustment
-4 to +2 m-¹
Movie - ISO sensitivity
M: Manual selection (ISO 100 to 25600; choose from step sizes of 1/3 and 1/2 EV); auto ISO sensitivity control (ISO 100 to 25600) available with selectable upper limit P, S, A: Auto ISO sensitivity control (ISO 100 to 25600) with selectable upper limit; Auto: Auto ISO sensitivity control (ISO 100 to 25600)
Audio output
Stereo mini-pin jack (3.5 mm diameter)
Camera VR
5-axis image sensor shift
Exposure lock
Luminosity locked at detected value
