Application

• Recommended Uses

• • Low light
  • Nature
  • Sports
  • Travel

Focal Length

• Focal length:- 300mm

• Focal length (equiv. 35mm):- 600mm

Lens Construction

• Lens configuration:- 17 elements / 10 groups

• ED lens elements:- 3 (Super ED)

• HR elements:- 3

• E-HR elements:- 1

• Focusing method:- High-speed Imager AF (MSC)

• Angle of view:- 4.1°

• Closest focusing distance:- 1.4m

• Maximum image magnification:- 0.24x (Micro Four Thirds) / 0.48x (35mm format)

• Minimum field size:- 72 x 54mm

Aperture

• Maximum aperture:- 1:4.0

• Minimum aperture:- 1:22

• Number of aperture blades:- 9 Circular aperture diaphragm for natural background blurring

Image Stabiliser

• Type:- VCM

• Effective Compensation Range:- Up to 6 EV steps* (5-axis Sync IS) Up to 4 EV steps (Lens IS)

• * As of December 2015. CIPA guideline compliant, when correction is carried out on two axes (yaw and pitch). When halfway release image stabilization is off.

Pro Features

• Dust, splash & freezeproof:- Yes

• Lens Hood locking:- Fixed mounting

• L-Fn Button:- Yes

• MF Clutch:- Yes

Dimensions

• Filter diamater:- 77mm

• Length:- 227mm / 280mm (hood retracted / hood extended)

• Diameter:- 92.5mm

• Weight:- 1270g (without tripod adapter) 1475g (with tripod adapter)

Cover & Cap

• Lens Cap:- LC-77B

• Lens Hood:- (Built-in)
